Cast Iron Gutter Profiles Explained: Half Round, Ogee, Moulded & More

Alumasc's standard Apex Heritage cast iron range contains four main gutter profiles across 11 standard profile-and-size combinations.

So, while "cast iron guttering" might sound like one fairly straightforward product, choosing the right system involves considerably more than deciding whether you want 4", 5" or 6" gutter.

Two gutters can have a similar nominal width but look completely different once they are fitted to a building. Their depth can differ. Their brackets and fittings can differ. One may look completely natural on a Victorian terrace, while another can look too decorative or too plain.

And if you're replacing existing cast iron guttering, the decision becomes even more important. A 125mm gutter isn't automatically compatible with another 125mm gutter simply because the number matches.

For the Alumasc Apex Heritage cast iron system we supply, the core standard profiles are Plain Half Round, Beaded Half Round, Victorian Ogee and Moulded. The range is based around traditional sand-cast detailing and socketed cast iron construction, with each profile available in its own selection of sizes and matching fittings.

So, which cast iron gutter profile should you actually choose?

This guide breaks down the differences in straightforward terms. We'll look at how each shape appears on a building, the sizes available, situations where each profile makes sense and, perhaps most importantly, what to check if you're trying to match guttering that's already on your property.

If you're still working out what the different cast iron measurements mean, our Cast Iron Guttering Sizes Explained guide is also worth reading alongside this one.

Cast Iron Gutter Profiles: Quick Cheat Sheet



Profile Before Price: What Does a Cast Iron Gutter Profile Actually Mean?

A gutter profile is simply the shape of the gutter when you look at it from the end.

Half Round is curved like the bottom half of a circle. Victorian Ogee has a more decorative, sculpted face. Moulded guttering has a deeper, more substantial shape. Beaded Half Round starts with the familiar curved form but adds raised detailing to the edges.

Above shows a standard 115mm cast iron plain half round gutter length.

Simple enough.

Where people get caught out is assuming that profile only affects appearance.

It doesn't.

Your chosen cast iron gutter profile can influence:

• the overall dimensions of the gutter
• how prominent it looks at the eaves
• its water-carrying characteristics
• which brackets fit it
• which outlets and angles you need
• how it connects with an existing system
• whether it looks appropriate on the building

This becomes particularly important during renovation work!

Imagine you've removed one damaged piece from an old Victorian house. You measure across it and find something close to 125mm. Ordering any modern 125mm cast iron gutter would be risky. You still need to determine whether the original is Half Round, Beaded Half Round, Victorian Ogee, Moulded or potentially a less common historic pattern.

Even two gutters that look similar from ground level may reveal obvious differences when viewed end-on.

The Apex Heritage system makes this easier because each profile has its own matching family of fittings. Alumasc's standard range includes Half Round in four nominal sizes, Beaded Half Round in two, Victorian Ogee in two and Moulded in three.

So, before thinking about colour, price or how many metres you need, answer one question first:

What profile does the building actually need?

For a new installation, that's partly an architectural choice. For a replacement project, matching what's already there will usually take priority.

And if you're unsure, don't guess from a photograph taken from the pavement. Take an end-on photograph of the gutter, measure its width and depth and check the socket arrangement as well.

Round and About: Why Plain Half Round Is the Straightforward Classic

If you picture traditional cast iron guttering, there's a good chance you're imagining Plain Half Round.

The profile does exactly what its name suggests. Viewed from the end, the water channel forms a simple semi-circular curve without decorative mouldings along its front edge.

That simplicity is one of its strengths.

Half Round doesn't shout for attention, so it can work across a wide range of traditional properties. It's useful when the rainwater system should complement the architecture rather than become one of its most decorative features.

Within Alumasc Apex Heritage, Half Round has the broadest standard size range:

The actual manufactured dimensions vary slightly from the nominal description. For example, Alumasc lists the 125mm HG50 gutter at an actual width of approximately 127mm and the 150mm HG60 at 150mm. The corresponding 1.83m sections weigh approximately 11.5kg and 13.5kg respectively.

That wider range makes Half Round particularly useful where roof sizes vary across a project.

A small porch or modest roof section may not require the same gutter size as the main elevation of a large house. Equally, going unnecessarily large can make the rainwater goods appear visually heavy.

Our Plain Half Round Cast Iron Gutters collection contains the matching gutter lengths, angles, outlets, brackets and stop ends required to build the system properly.

One other advantage is familiarity. If you've got an existing traditional curved cast iron gutter with no decorative front edge, Plain Half Round is the first profile I'd investigate.

Just don't rely on appearance alone. Check the measurements before ordering.

Bead It and See: When Half Round Needs a Little More Character

Beaded Half Round is the close relative of Plain Half Round, but one small design detail gives it a noticeably different appearance.

Alumasc describes the Apex Heritage version as having a pronounced feature bead on both lips of the gutter. In other words, the curved water channel is familiar, but the edges have additional definition rather than finishing as a completely plain curve.

It's subtle.

Some period properties benefit from more visual detail at the roofline, yet a full Victorian Ogee or Moulded profile can look more elaborate than the building calls for. Beaded Half Round sits neatly between those two ideas.

You retain the traditional curved gutter shape, while the bead creates a stronger edge and a slightly more architectural finish.

Apex Heritage Beaded Half Round comes in:

• 113mm / 4.5" — BG45
• 125mm / 5" — BG50

Both standard gutter lengths are 1.83m. Alumasc lists approximate section weights of 11kg for the 113mm profile and 12.5kg for the 125mm version.

That specification also highlights something important about cast iron gutter replacement.

Plain Half Round and Beaded Half Round can appear surprisingly similar from several metres below. Yet their actual profiles and corresponding fittings differ.

Don't therefore look at an existing curved gutter and assume:

"It's Half Round, that'll do."

Get close enough to inspect the front and rear lips.

Our Beaded Half Round Cast Iron Guttering range includes the matching fittings needed to keep the system consistent. That's particularly important around stop ends, outlets, fascia brackets and gutter joints.

Beaded Half Round makes most sense when you want something recognisably traditional without making the gutter one of the most visually dominant elements of the façade.

It's a relatively small detail from the pavement.

On the right property, though, small details are what make a roofline look right.

The Ogee Factor: Why Victorian Ogee Has So Much Presence

If Half Round is understated, Victorian Ogee heads in the other direction.

Ogee describes a profile based around opposing curves, creating the familiar flowing, decorative face associated with many traditional rainwater systems. Rather than simply forming a rounded channel, the front of the gutter becomes part of the building's architectural detailing.

That's why Victorian Ogee often catches the eye on period properties.

Within Apex Heritage, Alumasc offers Victorian Ogee in two standard nominal sizes:

• 113mm / 4.5" — OG45
• 125mm / 5" — OG50

Both come in standard 1.83m gutter lengths. The technical dimensions put the 113mm version at approximately 114mm wide and 54mm deep, while the 125mm version is around 127mm wide and 63mm deep.

There's another detail that matters if you're ordering fittings:

Apex Heritage Victorian Ogee is a left-hand socket system.

That's the sort of information that seems unimportant until you're trying to connect angles, stop ends and gutter runs on site.

Victorian Ogee works particularly well where the rainwater system is intended to form part of the traditional exterior detailing rather than disappear into the background. Think period façades, decorative eaves and restoration work where a plain modern-looking gutter would feel noticeably out of place.

However, decorative doesn't automatically mean better.

On a restrained cottage, barn conversion or simpler Georgian-style elevation, an ornate ogee profile could potentially fight with the architecture rather than complement it.

That's why we wouldn't choose profiles according to which one looks nicest in isolation.

Look at the whole building.

What gutter is already there? How decorative are the fascia, cornice and masonry details? Is this restoration, partial replacement or a completely new system?

Our Victorian Ogee Cast Iron Guttering collection gives you the complete Apex system once you've established that Ogee is the correct profile.

Above is that distinctive Ogee profile.

Mould Your Own: When the Roofline Calls for Something More Substantial

Then we come to Moulded cast iron guttering.

This is where the dimensions start looking noticeably different.

Rather than being described by one nominal width, Apex Heritage Moulded gutters are specified using both width and depth:

Those deeper dimensions give Moulded guttering a more substantial architectural presence than a simple Half Round system. Alumasc's current Apex range lists all three as standard Moulded profiles.

One small naming point is worth clearing up because it can otherwise become confusing when shopping online.

You may see terms such as Moulded, Moulded Ogee and traditional moulded gutter used around the industry. On our website you'll find the collection under Moulded Ogee Cast Iron Guttering, while Alumasc's technical literature refers to the Apex Heritage standard profile simply as Moulded.

The product code is therefore particularly useful when checking what you need.

Moulded cast iron guttering tends to make sense where the roofline needs more visual weight or where you're matching an existing deeper traditional system.

It can also be useful on larger elevations where a small Half Round profile might look visually undersized even if a drainage calculation suggested it could theoretically cope with the roof.

Gutter choice isn't only hydraulic engineering, and it isn't only architecture.

The best specification does both jobs.

You need a system capable of moving the required rainfall while also looking proportionate to the building.

For refurbishment work, though, matching comes first. If the property already has an original Moulded gutter, replacing one failed length with a superficially similar modern shape can leave you with incompatible joints, brackets and fittings.

Measure the complete profile before ordering.

Size Isn't Everything: 125mm Half Round Is Not the Same as 125mm Ogee

Here's one of the most useful things to understand when buying cast iron guttering:

the number on the product isn't the whole specification.

Take 125mm as an example.

Apex Heritage has a 125mm Half Round gutter, a 125mm Beaded Half Round gutter and a 125mm Victorian Ogee gutter. Moulded also has a 125 x 100mm option.

Those are four different products.

They don't suddenly become interchangeable because "125" appears in each description.

Profile affects the actual geometry of the gutter, the fittings required and potentially the amount of rainwater the section can accommodate. So if you're deciding which size is right for a roof, don't separate the question of size from the question of shape.

That's especially relevant if you're replacing an old system.

A useful identification checklist is:

• Measure the overall gutter width.
• Measure its depth.
• Photograph the profile directly from the end.
• Look for a bead along the gutter lips.
• Check whether the front has an Ogee-style curve.
• Photograph an existing joint and socket.
• Measure the downpipe as well.
• Check the outlet position and pipe shape.
• Note whether any original brackets are being retained.

If you're starting from scratch rather than replacing guttering, roof drainage requirements should also be considered properly.

A larger gutter isn't automatically necessary simply because it exists in the catalogue. Likewise, selecting the smallest option purely to reduce material cost is the wrong way around.

Our Cast Iron Guttering Sizes Explained guide goes further into roof area, outlets and downpipe sizing.

The easiest way to think about it is this:

Profile tells you what shape of system you need. Size tells you which version of that system you need.

Get both right.

Only then should you start calculating quantities.

The Great Gutter Match-Up: How to Identify an Existing Cast Iron Profile

Replacement projects are where cast iron gutter profiles become genuinely interesting.

A customer will often tell us:

"I've got old cast iron guttering and just need another section."

Makes sense. Unfortunately, that isn't enough information to safely specify the replacement.

Traditional rainwater systems have been manufactured for generations. Buildings have also been repaired, extended and altered. The gutter on one elevation might not even be identical to the gutter on another.

And old manufacturing tolerances can differ from modern components. Alumasc itself notes in guidance around heritage replacement that older systems cannot automatically be assumed to mix with current products merely because the profiles appear similar.

So how should you approach it?

Start with photographs.

We'd ideally want:

• a straight-on photograph of the gutter profile
• a photograph looking into the end or stop end
• a wider photo showing the whole roofline
• close-ups of the sockets and joints
• photos of any angles and outlets
• an image of the existing downpipe

Then add measurements.

Width is important, but depth can be just as revealing. If practical, measure an undamaged part rather than a section that's cracked, distorted or heavily built up with old paint.

Also look at the front edge.

A plain curve suggests Half Round. Raised edge detailing points towards Beaded Half Round. A flowing decorative face suggests Ogee. A deeper, more structured cross-section may indicate Moulded.

What shouldn't you do?

Choose the nearest-looking gutter from one photograph and hope the fittings line up.

If exact replacement isn't possible, it may be better to replace a complete run rather than creating an awkward transition between incompatible sections.

If you're planning that work yourself, our How to Install Cast Iron Guttering guide explains the Apex Heritage jointing, bracket positioning and fitting process in considerably more detail.

A few extra measurements now can save a very expensive wrong order later.

Beauty vs the Bucket: Balance Heritage Looks With Rainwater Capacity

Which cast iron gutter profile looks best?

There isn't one universal answer.

Which carries the most water?

Again, the answer depends on the exact profile, dimensions, fall, outlet configuration and roof area rather than simply the style name.

That's why choosing traditional rainwater goods becomes a balancing act.

You have several factors pulling at once:

• Appearance: Does the profile suit the building?
• Existing architecture: Are you matching original rainwater goods?
• Capacity: Can the complete system handle the roof drainage?
• Compatibility: Are the correct fittings and brackets available?
• Planning considerations: Is the property listed or in a conservation setting?
• Budget: Larger and more decorative castings can change the cost of the complete system.
• Installation: More complicated rooflines need more specialist fittings.

For a modest period property, Plain Half Round may be everything you need.

For another house, the bead along a Beaded Half Round gutter could be exactly the small architectural detail that ties the roofline together.

A Victorian façade with ornate exterior detailing might call for Victorian Ogee.

A substantial traditional building with deeper existing rainwater goods may point towards Moulded.

But don't let appearance overrule function.

The gutter, outlets and downpipes work as one drainage system. A beautiful profile connected to insufficient outlets or undersized pipework still leaves you with a poor rainwater design.

Equally, don't oversize everything without reason. An unnecessarily bulky gutter can upset the proportions of a smaller property.

If budget is driving your decision, our How Much Does Cast Iron Guttering Cost in the UK? guide explains where the money goes across gutter lengths, fittings, finishes and installation.

The goal is not to buy the biggest or most decorative cast iron gutter.

It's to buy the one that makes sense for your building.



The Final Cast: So Which Cast Iron Gutter Profile Should You Choose?

If you've made it this far, the choice should feel considerably simpler.

For the standard Alumasc Apex Heritage range we supply, you're primarily choosing between four profiles.

Plain Half Round is the straightforward traditional option. It has the broadest standard size range and works particularly well where you want cast iron character without a highly decorative front face.

Beaded Half Round keeps that curved shape but introduces additional edge detailing. Think familiar Half Round geometry with slightly more definition.

Victorian Ogee gives the roofline much more architectural character. Its curved decorative face works particularly well where traditional exterior detailing is an important part of the property.

Moulded is deeper and visually more substantial, making it particularly relevant where you're matching an existing traditional system or working with larger-scale architecture.

For replacement work, though, forget personal preference for a moment.

Match the building.

Measure the gutter. Identify the profile. Check the dimensions. Confirm the socket arrangement. Then work out the fittings you need.

And if you're unsure, send us photographs.

CastIronGuttering.co.uk specialises in the Alumasc Apex Heritage cast iron rainwater range, so we can help identify the likely gutter profile and work through the associated fittings rather than leaving you to piece a system together blindly.

Your practical job this week is simple: if you're replacing existing cast iron, take one clear end-on photograph and record both the width and depth of the gutter. Don't wait until you've removed half the roofline to discover the replacement doesn't match.
